| Model | Force Value （KN） |
Tightening Torque (mm) |
Thickness (mm) |
Weight (g) |
Package (pcs) |
|
| XM-KZD-Z1-C41 | 4.0 | 3.0 | 50 | 6 | 150 | 90 |
| XM-KZD-Z2-C41 | 8.0 | 5.0 | 50 | 6 | 540 | 40 |
| XM-KZD-Z3-C41 | 5.0 | 3.7 | 50 | 6 | 550 | 40 |
Practical application
■ Universal accessories, rigidly connected with channel steel or support arm with channel steel lock.
■ Suitable for various applications, easy to install, adjust position and disassemble.
■ Withstand high-strength vertical load, safe and reliable.
Installation
■ Strong assembly flexibility and easy installation.
■ Use patented channel steel lock to connect channel steel, and adjust it accurately according to actual working conditions.
Structural appearance
■ Innovative design without welding on the job site.
■ 90 ° angle to ensure the verticality of the installation.
Technology
■ Material: Q235B / SPHC, produced in accordance with JIS G 3131 standard.
■ Galvanized: electro-galvanized, thickened by 8μm and closed. Produced according to GB T 9799 standard.
■ Welding: mixed gas C O 2 shield welding, produced according to J B / T-9186-1999 standard production 9799 standard.
■ Other anti-corrosion treatment: hot dip galvanized, epoxy spray
